Y Type 8 Pin M12 Waterproof Connector 17P For Splitter Cable

Brand Name : RIGOAL

Model Number : m12 waterproof connector

Certification : CE，ROHS

Place of Origin : Shen zhen，China

MOQ : 100

Price : negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 100000

Delivery Time : 14

Packaging Details : 1.Our packaging:each pcs in one PE bag, then put in a small carton. 2.According to customer request.

Pins : 4p, 5P, 12p, 3P, 8P, 6P, 17P

Coding : A

IP Rating : IP67

Temperature Range : -40°C ~ + 125°C

Cable Length : Base on customer request

Coupling nut/screw : Brass with nickel plated screw

Brass with nickel plated screw : Male and female

Use : ≥250 times

Contact Now

Customized Waterproof Y Type M12 8 Pin 2 Female To 1 Male M12 8 Poles Connector Adapter For Y Shape Splitter Cable

Y Type 8 Pin M12 Waterproof Connector 17P For Splitter CableY Type 8 Pin M12 Waterproof Connector 17P For Splitter CableY Type 8 Pin M12 Waterproof Connector 17P For Splitter CableY Type 8 Pin M12 Waterproof Connector 17P For Splitter CableY Type 8 Pin M12 Waterproof Connector 17P For Splitter Cable

Y Type 8 Pin M12 Waterproof Connector 17P For Splitter Cable

M12 Adapter
Coding A / B / C / D / K / L / X / S / T Code
Number of Positions 3 / 4 / 5 / 8 / 12 / 17 Pin
Connector type M12 to M12 / M12 to RJ45
Terminal Direction T Type / Y Type / Straight / Right Angle
Rated Current 4A / 2A / 1.5A
Operating Voltage 250V / 60V / 30V
Temperature Range -25°C ~ + 80°C
IP Rating IP67
Code
The most common codes for waterproof connectors are A, B, C, D and X, and the table below describes the typical use for each code.
A-code For sensors and actuators
B-code For profibus (Process Field Bus) connections
C-code For AC power
D-code For 100Mb Ethernet
X-code For 10 Gigabit Ethernet

Advantages :
1. High degree of protection IP67, safe to use on site
2. High quality gold-plated solid phosphor bronze contacts , ≥ 600 times mating life
3. Anti-vibration locking screw design
4. Support samples, retail and bulk orders

5.IP Rating ip67/68 CE,ROHS


Product Tags:

8 Pin M12 Waterproof Connector



Y Type M12 Waterproof Connector



17P 8 Poles Connector
