M8 Waterproof Connector 90 Degree Assembly Male Male 4pins Connector Automation Application
Product description
M8 right angle female cable socket is hardwired and features 4 pins with a rated voltage of 60V. The cable entry accepts cable diameters of 4 to 5 mm. Strain relief via clamping cage. The ELWIKA 4008 V is designed for providing a quick and easy connection to a variety of applications.
- Housing Color- Black
- Type of Contact- Female Right Angle
- Number of Poles- 4
- Cable Gland- M9.5 x 1
- Rated Voltage- 60V AC/DC
- Rated Current- 4 Amps (2 A at 0.14mm2)
- Suitable Cable- 4 mm to 5 mm / 0.14 mm2 to 0.34 mm2
- Core Insulation of Connecting Leads- PVC, PETP, diameter 1.0 mm to 1.55 mm
- Protection Class- IP 67 (total protection from dust and temporary immersion in water - up to 1 meter for up to 30 min)
Quick details
1. M8 assembly connector 4pins male gender
2. Connector locking system is bolted
3. Termination is solder
4. Wire gauge(mm) is 0.25mm²
5. Wire gage(AWG) 24
6. Cable outlet can be 3,5 - 5,0 mm
7. Temperature will from -40° to +85°
8. Contacts 3.4.5.6.8pins avaliable
| Material Data |
| Contact material | CuZn (brass) |
| Contact plating | Au (gold) |
| Contact body material | PA |
| Housing material | PA |
Electrical values
Rated current (40 °C) :4 A
Rated voltage : 60 V
Rated impulse voltage :1500 V
Pollution degree :3
Overvoltage category :III
Insulating material group :III
Volume resistivity :≤ 3 mΩ
EMC compliance :not shielded
Degree of protection :IP67
Mechanical operation :> 100 Mating cycles
| Number of Contacts | 3 | 4 | 5 | 6 | 8 |
| Rated voltage | 30V | 60V |
| Contact resistance | <5mΩ |
| Insulation resistance | <100mΩ |
| Pollution degree | 3 |
| Temperature range | 25 °C to 85° C |
| Degree of protection | IP 67 when mated |
| Mating times | 100 cycles |
| Wire gauge | 24AWG | 26AWG |
| Cable jacket | PVC or PUR |
| Material of housing | Brass Nickel Plated |
| Material of insert | PA+GF UL9V-0 |
| Material of contact | Brass phosohor bronze gold plated
|
Product photos
Packsging & Shipping
1.Our general packing: PE bag and PE bag contons. General Carton size:40*30*30cm
2.Customized according to customer's request
M8 connector can be used a wide fields like LED, Automation, Sensor, mechanise equipment etc.
• LED lighting , white light , color light etc
• Low current equipement
• Connector be used in narrow environment
• Communication equipement
• Lighting harness
